Product Name Outdoor led billboard
Model Out-001
Material Aluminum
Brand Kordaled
LED SMD
Dimension 960mmx960mm
Pixel Pitch P4 P6 P8 P10 P3
Voltage 220-240V
Application 68
Refresh Rate 24hours
Reservation Now
Detail

NEW Wireless Led Display Outdoor led billboard led screen Scoreboard Concise Design Light Weight Cabinet Wireless Design Aluminum good quality of heat dissipation IP68/IP66


CabinetCabinet weight30KG/M2
Cabinet Dimension960mmX960mm
Cabinet Thickness(mm)75mm
Cabinet module quantity2x3
Cabinet Resolution48(W) x32 (H) pixels
Resolution (dots/SQM)10000dot
Materialaluminum
MTBF(Mean Time Between Failure)100000小时
Power consumption（W/㎡）：MAX\Average500w/150w
Refresh rate3840
Brightness≥9000nits
Drive TypeConstant Current 3 scan
Viewing AngleHorizontal 190°、Vertical 140°
Conrast Rate3500:1
Grey Scale16bit
Waterproof GradeIP66Front/IP66back
Receiving CardNova
DriverCE driver -400W
Maintenance Methodfront and back service
Single point brightness correctionYes
Single point color correctionYes
repetition frequency（Hz)47～63Hz
Color uniformity±0.003Cx,between Cy
Color temperature6500K~9500K adjustable
Working temrapure（°C)-85
Storage temperature range（°C）−20－60
Operating humidity range（RH)10-80%
Storage humidity range（RH)10-85%
Installationoutdoor fixed
Working VoltageAC110-220V±20%(V)-50/60Hz
