Product Name Outdoor led advertising billboard
Model Out-003
Material iron aluminum
Brand Kordaled
Guided smd gob
Dimension 1000x1000mm 960x960mm
Pixel Pitch P5 P4 P6 P8 P10 P3
Voltage 110-120V, 220v-240V
Application led billboard adverting video wall
Refresh Rate 3840
Reservation Now
Detail


OEM customized tailor bespoke caibnet led screen display   led wall
P2.5 white Aluminum outdoor fixed LED screen billboard

Cabinet weight28KG
Cabinet Dimension960mmX1120mm
Cabinet module quantity3x7
Mask42pcs
Cabinet Resolution384(W) x448 (H) pixels
Resolution (dots/SQM)62500
MaterialAluminum White
MTBF(Mean Time Between Failure)100000小时
Power consumption（W/㎡）：MAX\Average600w/240w
Refresh rate3840
Brightness≥5500-6000nits
Drive TypeConstant Current 4 scan
Viewing AngleHorizontal 160°、Vertical 140°
Conrast Rate3500:1
Grey Scale16bit
Waterproof GradeIP65
DriverCE driver MW LRS-350-5
